Pepwave SpeedFusion Engine ET

Serie: VELOCITY • Type: HARDWARE • Opprinnelse: CN

Produktnummer: SFE-DUO-LTE-US-ET Kategori: Peplink-produkter Stikkord: HARDWARE

Type: HARDWARE
Produktkode: SFE-DUO-LTE-US-ET

Brand	Peplink
Opprinnelsesland	CN

Mobility Legacy

Grensesnitt

Ytelse

Gjennomstrømning (ruter)	100Mbps ℹ️
SpeedFusion VPN Throughput (No Encryption)	40Mbps ℹ️
SpeedFusion VPN Throughput (256-bit AES)	20Mbps ℹ️
Anbefalte brukere	1–60
Maks administrerte AP/svitsjer	No

Trådløs

Antall mobilmodem	1 or 2
Mobilmodemkategori	2x CAT-3 1x CAT-4 2x CAT-4 2x CAT-6
5G support	No
SIM-spor	2 (no redundant slots)
SIM-kortstørrelse	Micro-SIM (3FF)
Wi-Fi-radio	No
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)	No
Wi-Fi Antenna Transmit Power (5GHz, single chain)	No
Flere SSID-er	No
GPS	Yes
RemoteSIM (used in SIM Injector)	Yes (HW2+)
FusionSIM	Yes (HW2+)
Peplink eSIM Data Plans	No
BYO eSIM	No

Funksjoner

SpeedFusion Hot Failover	Yes
SpeedFusion Smoothing	Yes
SpeedFusion Bandwidth Bonding	Yes
SpeedFusion Connect	Yes (HW2+)
SpeedFusion Relay Mode (Server)	Yes
Drop-In Mode	Yes
Høy tilgjengelighet	No
Peplink AP Series Management	No
Remote AP & Multiple Config Profiles Management	No
Switch Controller	No
WAN as LAN	Yes
LAN Bypass	No
InTouch	Yes
Virtual WAN	No
Synergy Mode (Controller)	No
Synergized Device	No
Application and Web Blocking	Yes
Web Content Filtering	Lite
IP Passthrough	No
IPv6	No
x.509 Certificate	Yes
Captive portal	Yes
GPIO	No
Tenningssensing	No
Netflow Support	Yes
LACP (802.3ad) NIC Bonding	No
Jumbo Frame Support	No
Intern lagring (edge computing)	No
Ekstern lagring via USB	No
Treghetsnavigasjon	No

Kjernefunksjonalitet

Inter-VLAN-ruting	Yes
VLAN-støtte (802.1q)	16
Port-Based VLAN	Yes
Lastbalansering (algoritmer)	8
Lastbalansering og failover	Yes
Innkommende lastbalansering	No
InControl 2 Cloud Management	Yes
InControl GPS Fleet Management	Yes

QoS

Båndbreddemonitorering	Yes
QoS for VoIP and E-Commerce	Yes
Brukergruppebasert båndbreddekontroll	Yes

VPN

SpeedFusion VPN	Yes
Antall SpeedFusion VPN-peers	2
IPsec VPN	Yes
Antall IPsec-tunneler	5
L2TP VPN / Open VPN / PPTP VPN Server	Yes
Maks PPTP/L2TP/OpenVPN-brukere	3
Remote RADIUS / LDAP authentication in Remote User Access	No
Antall OpenVPN-tunneler (site-to-site)	5
Antall GRE-tunneler (site-to-site)	5

Maskinvare

Innkapsling	Indoor,Metal
4pin Molex Micro-Fit Connector	No
Terminalblokk-strøm (kjøretøy)	Yes
Strømadapter/PSU	No
Innspenning	DC 12–24V
PoE Input	No
PoE Output	No
USB-strøminput	No
Nominalt strømforbruk	NA
Maks strømforbruk	15W
Dimensjoner (tommer)	2.95 x 3.25 x 1.65 inches
Dimensjoner (mm)	75 x 83 x 42 mm
Vekt (lbs)	0.77 pound
Vekt	350 grams
Driftstemperatur	-40°–149°F -40°–65°C
Luftfuktighet	15%–95% (non-condensing)
Rackmontering	No
Dobbel hot-swap strømforsyning	No
