Grensesnitt
| Antall WAN-porter | 2 (GE) |
|---|---|
| Antall LAN-porter | 7 (GE) |
| Maks WAN/LAN-konfigurasjon | 2 WAN with 7 LAN |
| SFP LAN / WAN | Nei |
| Serial Interface | Nei |
| Wi-Fi AP | Ja |
| Wi-Fi WAN | Ja |
| USB WAN | Ja (1x USB) |
| Module Expansion | Nei |
Ytelse
| Gjennomstrømning (ruter) | 2.5GbpsRouter Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. The throughput result is tested with DHCP/Static IP. |
|---|---|
| SpeedFusion VPN Throughput (No Encryption) | 600MbpsRouter Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. The throughput result is tested with DHCP/Static IP. |
| SpeedFusion VPN Throughput (256-bit AES) | 500MbpsRouter Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. The throughput result is tested with DHCP/Static IP. |
| Anbefalte brukere | 50-500 |
| Maks administrerte AP/svitsjer | 30 / 5050 AP is available as a license add-on (AP-LC-50). |
Trådløs
| Antall mobilmodem | 4 |
|---|---|
| Mobilmodemkategori | 4x CAT-12 2x 5G |
| 5G support | Ja |
| SIM-spor | 4 + 4 redundant slots |
| SIM-kortstørrelse | Nano-SIM (4FF) |
| Wi-Fi-radio | Dual (2.4GHz + 5GHz) 2x2 Wi-Fi 5 |
| Wi-Fi sendeeffekt 2,4 GHz | 24dBm |
| Wi-Fi sendeeffekt 5 GHz | 21dBm |
| Cellular Antenna Connectors | Embedded Cellular Antenna |
| Flere SSID-er | 16 |
| GPS | Ja |
| RemoteSIM (used in SIM Injector) | Ja |
| FusionSIM | Ja |
| Peplink eSIM Data Plans | JaRequire Firmware 8.3.0 or above. |
| BYO eSIM | JaRequire Firmware 8.4.0 or above. |
Funksjoner
| SpeedFusion Hot Failover | Ja |
|---|---|
| SpeedFusion Smoothing | Ja |
| SpeedFusion Bandwidth Bonding | Ja |
| SpeedFusion Connect | JaCarePlan subscription includes 2.5TB/year complimentary SpeedFusion Connect Usage data. |
| SpeedFusion Relay Mode (Server) | Ja |
| Drop-In Mode | Ja |
| Høy tilgjengelighet | Ja |
| Peplink AP Series Management | Ja |
| Remote AP & Multiple Config Profiles Management | Nei |
| Switch Controller | Ja |
| WAN as LAN | Nei |
| LAN Bypass | Nei |
| InTouch | Ja |
| Virtual WAN | JaUp to 3 Virtual WAN if purchasing Virtual WAN Activation Licence. |
| Synergy Mode (Controller) | Ja |
| Synergized Device | Ja |
| Application and Web Blocking | Ja |
| Web Content Filtering | Lite |
| IP Passthrough | JaAvailable for Firmware 8.5.0 or above. |
| IPv6 | JaSupport IP Passthrough mode. |
| x.509 Certificate | Ja |
| Captive portal | Ja |
| GPIO | Nei |
| Tenningssensing | Nei |
| Netflow Support | Ja |
| LACP (802.3ad) NIC Bonding | JaRequire Firmware 8.4.1 or above. |
| Jumbo Frame Support | Ja |
| Intern lagring (edge computing) | OptionalPlease contact Peplink Business Development team for details. |
| Ekstern lagring via USB | JaSupport Docker. |
| Treghetsnavigasjon | Ja |
Kjernefunksjonalitet
| Inter-VLAN-ruting | Ja |
|---|---|
| VLAN-støtte (802.1q) | 128 |
| Port-Based VLAN | Ja |
| Lastbalansering (algoritmer) | 8 |
| Lastbalansering og failover | Ja |
| Innkommende lastbalansering | Nei |
| InControl 2 Cloud Management | Ja |
| InControl GPS Fleet Management | Ja |
QoS
| Båndbreddemonitorering | Ja |
|---|---|
| QoS for VoIP and E-Commerce | Ja |
| Brukergruppebasert båndbreddekontroll | Ja |
VPN
| SpeedFusion VPN | Ja |
|---|---|
| Antall SpeedFusion VPN-peers | 3 or 20Require license to increase maximum number of PepVPN/SpeedFusion Peers. Several option are available based on the model 5, 10 or 20 peers (PVN-LC-05, PVN-LC-10, PVN-LC-20). |
| IPsec VPN | Ja |
| Antall IPsec-tunneler | 5 |
| L2TP VPN / Open VPN / PPTP VPN Server | Ja |
| Maks PPTP-, L2TP- og OpenVPN-brukere | 15 |
| Remote RADIUS / LDAP authentication in Remote User Access | Ja |
| Antall OpenVPN-tunneler (site-to-site) | 5 |
| Antall GRE-tunneler (site-to-site) | 5 |
Maskinvare
| Innkapsling | Pelican case |
|---|---|
| 4pin Molex Micro-Fit Connector | Nei |
| Terminalblokk-strøm (kjøretøy) | Nei |
| Strømadapter eller PSU | Nei |
| Innspenning | DC 12-56V AC 100-240V |
| PoE Input | Nei |
| PoE Output | Up to 7x 802.3at PoE+ |
| USB-strøminput | Nei |
| Nominalt strømforbruk | NA |
| Maks strømforbruk | 38W (w/o PoE) |
| Dimensjoner (tommer) | 19.78 x 15.77 x 7.41 inch |
| Dimensjoner (mm) | 502 x 401 x 188 mm |
| Vekt (lbs) | 34.53 pounds |
| Vekt | 15.68 kg |
| Driftstemperatur | -40°-113°F -40°-45°C |
| Luftfuktighet | 15%-95% (non-condensing) |
| Rackmontering | Nei |
| Dobbel hot-swap strømforsyning | Nei |
Garanti
| Garanti | 1-Year Limited Warranty |
|---|
