Serie: BLUECHIP • Type: Garanti / Support (Peplink Care)
EssentialCare+ includes:
EssentialCare+ begins and is activated on the date of payment confirmation. It will take effect in approximately 1 hour. EssentialCare+ is non-transferable and non-refundable.
Produktkode: ECP-BPL-SDX-PRO-M2-1TB-4Y
| Brand | Peplink |
|---|---|
| Produkttype | Garanti / Support (Peplink Care) |
| Antall WAN-porter | 2–10 (GE) ℹ️ |
|---|---|
| Antall LAN-porter | 8–18 (GE) ℹ️ |
| Maks WAN/LAN-konfigurasjon | 10 WAN with 8 LAN 0 WAN with 18 LAN |
| SFP LAN / WAN | 2 / 6 (10G SFP+) ℹ️ |
| Serial Interface | No |
| Wi-Fi AP | No |
| Wi-Fi WAN | No |
| USB WAN | Yes (2x USB) |
| Module Expansion | Yes (1 slot for FlexModule Plus) |
| Gjennomstrømning (ruter) | 12Gbps ℹ️ |
|---|---|
| SpeedFusion VPN Throughput (No Encryption) | 1Gbps ℹ️ |
| SpeedFusion VPN Throughput (256-bit AES) | 600Mbps ℹ️ |
| Maks administrerte AP/svitsjer | 250 |
| Anbefalte brukere | 500–2000 |
| Antall mobilmodem | Up to 4 ℹ️ |
|---|---|
| Mobilmodemkategori | 3x CAT-6 (With FlexModule Plus) 4x CAT-12 (With FlexModule Plus) 2x CAT-20 (With FlexModule Plus) 2x 5G (With FlexModule Plus) |
| 5G support | Yes |
| SIM-spor | Up to 8 ℹ️ |
| SIM-kortstørrelse | Mini-SIM (2FF) |
| Wi-Fi-radio | No |
| Wi-Fi Antenna Transmit Power (2.4GHz, single chain) | No |
| Wi-Fi Antenna Transmit Power (5GHz, single chain) | No |
| Flere SSID-er | No |
| GPS | Yes ℹ️ |
| RemoteSIM (used in SIM Injector) | Yes (HW3+) ℹ️ |
| FusionSIM | Yes (HW3+) ℹ️ |
| Peplink eSIM Data Plans | Yes ℹ️ |
| BYO eSIM | Yes ℹ️ |
| SpeedFusion Hot Failover | Yes |
|---|---|
| SpeedFusion Smoothing | Yes |
| SpeedFusion Bandwidth Bonding | Yes |
| SpeedFusion Connect | Yes ℹ️ |
| SpeedFusion Relay Mode (Server) | Yes |
| Drop-In Mode | Yes |
| Høy tilgjengelighet | Yes |
| Peplink AP Series Management | Yes |
| Remote AP & Multiple Config Profiles Management | Yes |
| Switch Controller | Yes |
| WAN as LAN | Yes |
| LAN Bypass | No |
| InTouch | Yes |
| Virtual WAN | Yes ℹ️ |
| Synergy Mode (Controller) | Yes |
| Synergized Device | No |
| Application and Web Blocking | Yes |
| Web Content Filtering | Full |
| IP Passthrough | Yes |
| IPv6 | Yes |
| x.509 Certificate | Yes |
| Captive portal | Yes |
| GPIO | No |
| Tenningssensing | No |
| Netflow Support | Yes |
| LACP (802.3ad) NIC Bonding | Yes ℹ️ |
| Jumbo Frame Support | Yes |
| Intern lagring (edge computing) | No |
| Ekstern lagring via USB | Yes ℹ️ |
| Treghetsnavigasjon | Yes ℹ️ |
| Inter-VLAN-ruting | Yes |
|---|---|
| VLAN-støtte (802.1q) | 1024 |
| Port-Based VLAN | Yes |
| Lastbalansering og failover | Yes |
| Lastbalansering (algoritmer) | 8 |
| Innkommende lastbalansering | Yes |
| InControl 2 Cloud Management | Yes |
| InControl GPS Fleet Management | Yes ℹ️ |
| Båndbreddemonitorering | Yes |
|---|---|
| QoS for VoIP and E-Commerce | Yes |
| Brukergruppebasert båndbreddekontroll | Yes |
| SpeedFusion VPN | Yes |
|---|---|
| Antall SpeedFusion VPN-peers | 300 |
| IPsec VPN | Yes |
| Antall IPsec-tunneler | 200 |
| L2TP VPN / Open VPN / PPTP VPN Server | Yes |
| Maks PPTP/L2TP/OpenVPN-brukere | 200 |
| Remote RADIUS / LDAP authentication in Remote User Access | Yes |
| Antall OpenVPN-tunneler (site-to-site) | 5 |
| Antall GRE-tunneler (site-to-site) | 5 |
| Innkapsling | Indoor,Metal |
|---|---|
| 4pin Molex Micro-Fit Connector | No |
| Terminalblokk-strøm (kjøretøy) | No |
| Strømadapter/PSU | Power Cord (ACW-614) |
| Innspenning | AC 100–240V |
| PoE Input | No |
| PoE Output | Yes |
| USB-strøminput | No |
| Nominalt strømforbruk | 80W for the main chassis 20W consumption for the optional module. |
| Maks strømforbruk | System + 330W PoE+ budget |
| Dimensjoner (tommer) | 17.2 x 13.3 x 1.7 inches |
| Dimensjoner (mm) | 438 x 340 x 44 mm |
| Vekt (lbs) | 11.7 pounds |
| Vekt | 5.3 kg |
| Driftstemperatur | 32°–104 °F 0°–40°C |
| Luftfuktighet | 5%–90% (non-condensing) |
| Rackmontering | 1U |
| Dobbel hot-swap strømforsyning | No |
| Garanti | 1-Year Limited Warranty |
|---|
