Grensesnitt
| Antall WAN-porter | 2 (GE) |
|---|---|
| Antall LAN-porter | 4 (GE) |
| Maks WAN/LAN-konfigurasjon | 2 WAN with 4 LAN |
| SFP LAN / WAN | Nei |
| Serial Interface | Nei |
| Wi-Fi AP | Ja |
| Wi-Fi WAN | Ja |
| USB WAN | Ja (1x USB-C) |
| Module Expansion | Nei |
Ytelse
| Gjennomstrømning (ruter) | 1GbpsRouter Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. The throughput result is tested with DHCP/Static IP. |
|---|---|
| SpeedFusion VPN Throughput (No Encryption) | 400MbpsRouter Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. The throughput result is tested with DHCP/Static IP. |
| SpeedFusion VPN Throughput (256-bit AES) | 200MbpsRouter Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. The throughput result is tested with DHCP/Static IP. |
| Anbefalte brukere | 1-150 |
| Maks administrerte AP/svitsjer | 30 / 5050 AP is available as a license add-on (AP-LC-50). |
Trådløs
| Antall mobilmodem | 1 |
|---|---|
| Mobilmodemkategori | 1x CAT-4 |
| 5G support | Nei |
| SIM-spor | 2 |
| SIM-kortstørrelse | Nano-SIM (4FF) |
| Wi-Fi-radio | Dual (2.4GHz + 5GHz) 2x2 Wi-Fi 6 |
| Wi-Fi sendeeffekt 2,4 GHz | 20dBm |
| Wi-Fi sendeeffekt 5 GHz | 24dBm |
| Cellular Antenna Connectors | 4x SMA Cellular ConnectorsCompatible with ACW-235 LTE/5G Antennas. |
| Flere SSID-er | 16 |
| GPS | Nei |
| RemoteSIM (used in SIM Injector) | Ja (HW2+) |
| FusionSIM | Ja (HW2+) |
| Peplink eSIM Data Plans | JaModels with selected SKU support eSIM. |
| BYO eSIM | Ja |
Funksjoner
| SpeedFusion Hot Failover | Ja Require PrimeCare Subscription, complimentary for the first year. |
|---|---|
| SpeedFusion Smoothing | Ja Require PrimeCare Subscription, complimentary for the first year. |
| SpeedFusion Bandwidth Bonding | Ja Require PrimeCare Subscription, complimentary for the first year. |
| SpeedFusion Connect | JaPrimeCare subscription includes 500GB/year complimentary SpeedFusion Connect Usage data. |
| SpeedFusion Relay Mode (Server) | Ja |
| Drop-In Mode | Ja |
| Høy tilgjengelighet | Ja |
| Peplink AP Series Management | Ja |
| Remote AP & Multiple Config Profiles Management | Nei |
| Switch Controller | Ja |
| WAN as LAN | Nei |
| LAN Bypass | Nei |
| InTouch | Ja |
| Virtual WAN | Ja1 Virtual WAN complimentary with active PrimeCare. Up to 3 Virtual WAN upon purchasing Virtual WAN Activation Licence. |
| Synergy Mode (Controller) | Ja |
| Synergized Device | Ja |
| Application and Web Blocking | Ja |
| Web Content Filtering | Full |
| IP Passthrough | Ja |
| IPv6 | JaSupport IP Passthrough mode. |
| x.509 Certificate | JaRequire IPsec X.509 Certificate License Key. |
| Captive portal | Ja |
| GPIO | Ja |
| Tenningssensing | Nei |
| Netflow Support | Ja |
| LACP (802.3ad) NIC Bonding | Nei |
| Jumbo Frame Support | Ja |
| Intern lagring (edge computing) | Nei |
| Ekstern lagring via USB | JaRequires FW 8.5.2+ with a perpetual software license (LIC-DOC), or FW 8.6.0+ with active PrimeCare, to enable Docker. |
| Treghetsnavigasjon | Nei |
Kjernefunksjonalitet
| Inter-VLAN-ruting | Ja |
|---|---|
| VLAN-støtte (802.1q) | 16 |
| Port-Based VLAN | Ja |
| Lastbalansering (algoritmer) | 8 |
| Lastbalansering og failover | Ja |
| Innkommende lastbalansering | Nei |
| InControl 2 Cloud Management | Ja |
| InControl GPS Fleet Management | Nei |
QoS
| Båndbreddemonitorering | Ja |
|---|---|
| QoS for VoIP and E-Commerce | Ja |
| Brukergruppebasert båndbreddekontroll | Ja |
VPN
| SpeedFusion VPN | Ja |
|---|---|
| Antall SpeedFusion VPN-peers | 2 / 5 / 10 / 202 SpeedFusion VPN Peers are enabled by default. 5 SpeedFusion VPN Peers are enabled with PrimeCare Subscription, complimentary for the first year. 10 or 20 SpeedFusion VPN peers can be enabled with software license (PVN-LC-10 and PVN-LC-20). |
| IPsec VPN | Ja |
| Antall IPsec-tunneler | 5 |
| L2TP VPN / Open VPN / PPTP VPN Server | Ja |
| Maks PPTP-, L2TP- og OpenVPN-brukere | 15 |
| Remote RADIUS / LDAP authentication in Remote User Access | Nei |
| Antall OpenVPN-tunneler (site-to-site) | 5 |
| Antall GRE-tunneler (site-to-site) | 5 |
Maskinvare
| Innkapsling | Indoor,Plastic |
|---|---|
| 4pin Molex Micro-Fit Connector | Ja |
| Terminalblokk-strøm (kjøretøy) | Nei |
| Strømadapter eller PSU | AC Input 100V-240V DC Output 12V 3A Compatible with ACW-672. |
| Innspenning | DC 10-30V |
| PoE Input | Nei |
| PoE Output | Nei |
| USB-strøminput | Nei |
| Nominalt strømforbruk | 6W |
| Maks strømforbruk | 17WMaximum without USB-C output. |
| Dimensjoner (tommer) | 10.31 x 6.33 x 1.31inch |
| Dimensjoner (mm) | 262 x 161 x 33.5mm |
| Vekt (lbs) | 1.7 pounds |
| Vekt | 761 grams |
| Driftstemperatur | -40°-113°F -40°-45°C |
| Luftfuktighet | 10%-90% (non-condensing) |
| Rackmontering | Nei |
| Dobbel hot-swap strømforsyning | Nei |
Garanti
| Garanti | 1-Year Limited Warranty |
|---|
